ASTM A210 Grade C Tube Manufacturer and Supplier in India
Fin Tubes is a well-known manufacturer and supplier of ASTM A210 Grade C Tubes in India, and we manufacture products designed to fulfill the needs of stringent industrial requirements. Our tubes are manufactured with adherence to global quality norms and are made with high-quality materials through the use of advanced manufacturing techniques to provide optimum durability. Various sizes of ASTM A210 Grade C Tubes are available at Fin Tubes, and we have been able to win the confidence of many customers both nationally and internationally because of our commitment to quality and reasonable prices.
-
ISO 9001:2015Certified Company
-
High-qualityRaw Material
-
ExportWorldwide
-
Mill TestCertificate
Overview of ASTM A210 Grade C Tube
The ASTM A210 grade C tubes are seamless tubes made of medium-carbon steel. The tubes are designed specifically for high-temperature and high pressure applications. The tubing is made per the ASTM A210 / ASME SA21 specification and is welded and has high tensile strength. They have an excellent surface finish and dimensional tolerances, which help increase the life of equipment and smooth flow of fluids. ASTM A210 Grade C Tubes are manufactured with high quality raw materials and advanced manufacturing processes, and the tubes are inspected rigorously to ensure the consistency of the products. They are extensively used in power plants, boilers, heat exchangers, condensers, refineries, and in various other industrial applications where reliable strength and high temperature resistance are required.
Technical Data
Specifications of ASTM A210 Grade C Tube
| Specification | Details |
|---|---|
| Standards | ASTM A210/A210M (ASME SA210/SA210M) |
| Outer Diameter (O.D.) | From 3/4 to 20 inch |
| Wall Thickness | 0.8 to 15 mm |
| Length | Max 16000 mm, 5 to 25 mm |
| Application | Seamless Carbon Steel Boiler Tubes for High-Temperature Service |
| Packing | Bare packing, bundle packing, crate packing, or wooden protection at both sides of tubes; suitably protected for sea-worthy delivery or as requested. |
| Inspection and Test | Chemical Composition Inspection, Mechanical Properties Test (Tensile Strength, Yield Strength, Elongation, Flaring, Flattening, Bending, Hardness, Impact Test), Surface and Dimension Test, Non-destructive Test, Hydrostatic Test. |
| Surface Treatment | Oiled, black painted, shot blasted, hot-dipped galvanized, or phosphate coating. |
ASTM A210 Grade C Chemical Compositions
| Grade | C (%) | Si (%) | Mn (%) | P (%) | S (%) | Mo (%) | Cr (%) | V (%) |
|---|---|---|---|---|---|---|---|---|
| C | <= 0.35 | >= 0.10 | 0.29 - 1.06 | <= 0.035 | <= 0.035 | - | - | - |
Mechanical Properties of ASTM A210 Grade C Tubes
| Grade | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (HRB) |
|---|---|---|---|---|
| C | >= 485 | >= 275 | >= 30 | <= 89 |
ASTM A210 Grade C Tube Wall Thickness Tolerance Chart
| Outside DiameterIn. (mm) | Wall Thickness Tolerance (%)Over (+) | Wall Thickness Tolerance (%)Under (-) |
|---|---|---|
| 1 1/2 (38.1) and under | 20 | 0 |
| Over 1 1/2 (38.1) | 22 | 0 |
Dimension Chart of ASTM A210 Grade C Tube
| Outside DiameterIn. (mm) | Permissible Variations Over (+)In. (mm) | Permissible Variations Under (-)In. (mm) |
|---|---|---|
| Under 1 (25.4) | 0.004 (0.10) | 0.004 (0.10) |
| 1 to 1 1/2 (25.4 to 38.1), Incl | 0.006 (0.15) | 0.006 (0.15) |
| Over 1 1/2 to 2 (38.1 to 50.8), Excl | 0.008 (0.20) | 0.008 (0.20) |
| 2 to 2 1/2 (50.8 to 63.5), Excl | 0.010 (0.25) | 0.010 (0.25) |
| 2 1/2 to 3 (63.5 to 76.2), Excl | 0.012 (0.30) | 0.012 (0.30) |
Where They Are Used
Applications
- Power Generation Industry
- Boiler Manufacturing Industry
- Petrochemical Industry
- Oil & Gas Industry
- Chemical Processing Industry
- Fertilizer Industry
- Heat Exchanger Manufacturing Industry
- Refining Industry
Power Generation Plants
Petrochemical Plants
Heat Exchangers
Air Preheaters
Industries We Serve
Boilers
Heat Exchangers
Power Plants
Frequently Asked Questions
Have more questions? Send an enquiry and we will respond within one working day.
ASTM A210 Grade C Tube is a seamless medium-carbon steel tube designed for high-temperature and high-pressure boiler and superheater applications.
ASTM A210 Grade C is a medium-carbon steel material known for its high strength, good heat resistance, and excellent mechanical properties.
ASTM A210 Grade C Tubes are primarily manufactured in seamless form as specified by the ASTM A210 standard.
ASTM A210 Grade C Tubes are designed for high-temperature service and are commonly used in applications operating up to approximately 500°C (932°F), depending on design conditions.
ASTM A210 Grade C Tubes comply with ASTM A210 and the equivalent ASME SA210 specification for seamless medium-carbon steel boiler and superheater tubes.
Request a Quote for ASTM A210 Grade C Tube
ASTM A210 Grade C Tube manufacturer in India offering seamless medium carbon steel boiler tubes with high strength, excellent heat resistance, and reliable performance for boilers, heat exchangers, and condensers.
