A334 Grade 1 Tube Manufacturer and Supplier in India
Fin Tubes is a trustworthy manufacturing and supplying company of ASTM A334 Grade 1 Tubes in India, providing excellent low-temperature carbon steel tubes for various industries. Produced from the best quality raw material with advanced technological processes, our tubes assure exceptional toughness and accurate dimensions with excellent performance even in low-temperature conditions. We provide ASTM A334 Grade 1 Tubes in different sizes and specifications to fulfill the requirements of various projects. Our company is dedicated to delivering quality products at competitive prices along with timely deliveries.
-
ISO 9001:2015Certified Company
-
High-qualityRaw Material
-
ExportWorldwide
-
Mill TestCertificate
Overview of A334 Grade 1 Tubes
ASTM A334 Grade 1 Tubes are Low Temperature Carbon Steel Tubes are produced to ensure reliable performance at sub zero temperatures. These tubes are manufactured to meet ASTM A334/ ASME SA334 specifications and can be produced in seamless or welded variety as per the requirement of the industries. A wide variety of sizes, ranging from 1/4" O.D. to 2" O.D., and wall thicknesses from 1mm to 8mm are widely used and made to order. ASTM A334 Grade 1 Tubes are readily welded and have good toughness and dimensional accuracy characteristics, suitable for use in pressure piping, cryogenic equipment, heat exchange equipment, and process systems. They are also excellent materials for forming, machining, galvanizing and heat treatment processes, providing additional versatility in industrial applications.
Technical Data
Specifications of A334 Grade A1 Tube
| Specification Parameter | Details |
|---|---|
| Standard Specifications | ASTM A 334, ASME SA 334 |
| Material Grade | Grade 1 |
| Type | Seamless / Welded / Low Temperature |
| Supplier Size Ranges | 4" NB to 26" NB |
| Outer Dimensions (OD) | 6 mm - 1020 mm |
| Wall Thickness (WT) | 2.0 mm - 14 mm |
| Schedules | 20, 30, 40, Standard (STD), Extra Heavy (XH), 80, 100, 120, 140, 160, XXH & heavier |
| Length Options | 5800 mm; 6000 mm; 6096 mm; 7315 mm; 11800 mm, etc. |
Chemical Properties of ASTM A334 Grade 1
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| max 0.30 | - | 0.40 - 1.06 | 0.025 | 0.025 | - | - | - | - | - |
Mechanical Properties of ASTM A334 Grade 1
| Yield StrengthMPa min | Yield Strengthksi min | Tensile StrengthMPa min | Tensile StrengthMPa min | Tensile Strengthksi min | Elongation A5 minPercentage |
|---|---|---|---|---|---|
| - | - | 380 | - | 55 | 35 |
Equivalent Grades of A334 Grade 1 Tubes
| DIN | EN | BS | NFA | ASTM | ASME |
|---|---|---|---|---|---|
| - | EN P215NL Grade 10217-4 | - | ASTM A334 Grade 1 | ASME SA 334 Grade 1 | - |
Where They Are Used
Applications
- Thermal Power Plants
- Combined Cycle Gas Turbine (CCGT) Power Plants
- Oil Refineries
- Petrochemical Manufacturing Plants
- Fertilizer Production Plants
- Pulp & Paper Manufacturing Mills
- Sugar Mills & Cogeneration Plants
- Industrial Boiler & Heat Exchanger Manufacturing Industry
Power Generation Plants
Petrochemical Plants
Heat Exchangers
Air Preheaters
Industries We Serve
Boilers
Heat Exchangers
Power Plants
Frequently Asked Questions
Have more questions? Send an enquiry and we will respond within one working day.
ASTM A334 Grade 1 Tubes are used for low-temperature piping, heat exchangers, pressure vessels, and cryogenic process systems.
ASTM A334 Grade 1 is a low-carbon steel material designed for low-temperature service with good toughness and weldability.
Yes. ASTM A334 Grade 1 Tubes are specifically designed for low-temperature applications where reliable toughness is required.
ASTM A334 Grade 1 Tubes are typically used in low-temperature applications down to -45°C (-50°F).
Grade 6 has higher strength and better low-temperature impact toughness than Grade 1, making it suitable for more demanding cryogenic applications.
ASTM A334 Grade 1 Tubes are available in both seamless and welded forms, depending on the application requirements.
Request a Quote for ASTM A334 Grade 1 Tubes
Buy ASTM A334 Grade 1 Tubes from a leading manufacturer and supplier in India. Fin Tubes offers ASME SA334 Grade 1 seamless low-temperature carbon steel tubes for cryogenic, pressure piping, and industrial applications.
