ASTM A519 1010 Tubes Manufacturer and Supplier in India
Fin Tubes supplies ASTM A519 Grade 1010 Tubes to customers across engineering, automotive and general fabrication sectors, backed by strict process control and material traceability at every stage. As a trusted A519 1010 Tube Manufacturer and Supplier in India, we produce seamless carbon steel mechanical tubing in cold drawn and hot finished conditions, tailored for components that demand consistent machinability and dimensional accuracy rather than pressure containment duty.
-
ISO 9001:2015Certified Company
-
High-qualityRaw Material
-
ExportWorldwide
-
Mill TestCertificate
Overview of ASTM A519 1010 Tube
ASTM A519 Grade 1010 Tube is a low carbon seamless mechanical tube grade with a carbon content of 0.08 to 0.13 percent and manganese content of 0.30 to 0.60 percent, manufactured as per the ASTM A519 and ASME SA519 standards. This low carbon composition gives Grade 1010 good ductility and ease of cold working compared to higher carbon grades under the same specification. These tubes are produced as seamless mechanical tubing rather than pressure tubing, and are commonly chosen for structural components, machined parts and general engineering applications where strength, formability and dimensional consistency matter more than heat transfer performance.
Technical Data
Specifications of ASTM A519 1010 Tube
| Parameter | Details |
|---|---|
| Standard | ASTM A519 |
| Grade | 1010 |
| Type | Seamless |
| Outer Diameter | 6 mm to 273 mm |
| Wall Thickness | 0.5 mm to 25 mm |
| Length | Up to 7 meters, Single Random or Cut Length |
| Form | Round, Square, Rectangular |
| Condition | Cold Drawn, Hot Finished |
| Ends | Plain End |
| Application | Mechanical and Structural Tubing |
Chemical Properties of ASTM A519 1010 Tube
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| 0.08-0.13 | - | 0.30-0.60 | 0.04 | 0.05 | - | - | - | - | - |
Mechanical Properties of ASTM A519 1010 Tube
| Yield Strength MPa min | Yield Strength ksi min | Tensile Strength MPa min | Tensile Strength MPa min | Tensile Strength ksi min | Elongation A5 min Percentage |
|---|---|---|---|---|---|
| - | - | - | - | - | - |
Applications
- Automotive Components
- Hydraulic Cylinder Tubes
- Machinery and Equipment Parts
- Construction Equipment
- Agricultural Machinery
- General Engineering Fabrication
- Structural Framing Components
- Mechanical Assemblies
Power Generation Plants
Petrochemical Plants
Heat Exchangers
Air Preheaters
Industries We Serve
Boilers
Heat Exchangers
Power Plants
Frequently Asked Questions
Have more questions? Send an enquiry and we will respond within one working day.
Grade 1010 refers to the carbon content and chemical composition of the steel used, indicating a low carbon mechanical tube grade suited for cold working, bending and machining operations.
Yes, A519 1010 tubes are commonly used for hydraulic and pneumatic cylinder parts because of their good ductility, smooth finish and dimensional accuracy after cold drawing.
A519 1010 tubes can be supplied in either cold drawn or hot finished condition depending on the required strength, surface finish and dimensional tolerance for the application.
A519 1010 tubes are intended for mechanical and structural use, not pressure vessel or boiler service, so they are not a substitute for pressure rated tube specifications.
A519 1010 tubes are available in round, square and rectangular sections, allowing them to be used across a wide range of mechanical and structural fabrication needs.
Request a Quote for ASTM A519 1010 Tubes
Fin Tubes manufactures ASTM A519 Grade 1010 seamless mechanical tubes in India, cold drawn & hot finished carbon steel tubing. Request a quote now.
